Electric Chain Hoist

Electric Chain Hoist
Electric Chain Hoist
Send Inquiry
Product Code : 03
Brand Name : anker
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 100000.00 - 800000.00 INR
Product Specifications
  • Usage
  • Industrial
  • Power Source
  • Electric
  • Sling Type
  • Chain
Product Description

With the support of a highly professional team, we are highly renowned as the topmost manufacturer and exporter of the best quality Electric Chain Hoist. Widely used in industries for material handling work, these hoists are offered to clients in different specifications and models for meeting their individual requirements. Our highly experienced team uses best quality materials for manufacturing the entire range of Electric Chain Hoist. We are offering these hoists to clients at competitive price.

Features:

  • High load bearing capacity
  • Simple and quick installation
  • Consumes less power

Hoist Details:

Weight of Hoist at 3 Mtr. Lift

35 Kgs.

Extra Weight per Meter

1.2 Kgs.

No. of Falls of Load Chain

1 Falls

Overall Dimensions

560 x 410 x 265 mm (Head room x Other Dimensions)

Headroom (Hook Suspension)

560 mm

Headroom (With Monorail Geared Traveling Trolley

600 mm

Headroom (With Monorail Electric Traveling Trolley)

620 mm

Motor

0.5 HP, 3 Phase, 1440 RPM, Class F, 40% Intermittent Duty, Induction Motor

Hoisting Speed:

6.4 Mtr./ Min

Exceptions to EH2 Hoist

6.3 mm, Grade 80, Alloy Steel Material Load Chain


Specifications:


  • Configured in two separated self-directed units – Execution Sides (Driven Parts), Motor Sides (Driving Parts)
  • Handled by Squirrel Cage Induction Motor built-in with electromagnetic brakes.
  • Duty: Class II, 40% Periodical duty
  • Factory-made as per IS: 6547 (Indian Standard)
  • Time-tested at 25 % of Overload
  • Hooks: Made as per IS: 15560 - 2005
  • Load Chain: 12 mm, Alloy Steel Material as per IS: 6216, Grade 80,
  • Load Chain Wheel: Have S.G. Iron Casting – accurately pocketed
  • Gears: Made with alloy steel material, exactly machined, gear hobbed, case treated – duly tempered. Spur / Coiling assemblage to give strength & fast operation.
  • Motor: Squirrel Cage Induction Motors for Hoist Duty, with advanced starting torques – operative on 415 Volts, 3 Phases, 50 Hz AC supply with electromagnetic Brakes. Ceaselessly rated, appropriate for regular braking and reversing.
  • Braking Execution: A.C. Electromagnetic Brakes
  • Control Panel Unit: Completely besieged to protect from adverse weather conditions, provide outputs at 24 volts to the useable control station (Push Button Station).
  • Functional Control Station: Supported from hoist with cables & supporting wire ropes – with two push buttons extendible to four / six push buttons station. Directed with 24 Volts.
  • Overload Relays: These are provided for the protection of Motor.
  • Limit Switches: Furnished to control motility of Hooks in Hoisting occurrence at distinct levels excited by Lower Hooks & End Stops. Precludes accidents that can due to over-lowering and over-hoisting.

Technical Details:

Capacity:

3.0 Ton

5.0 Ton

7.5 Ton

10.0 Ton

Weight of Hoist at

3 Mtr. Lift: 385 Kgs.

3 Mtr. Lift: 395 Kgs.

3 Mtr. Lift: 405 Kgs.

3 Mtr. Lift: 415 Kgs.

Extra Weight per Meter:

3.3 Kgs.

6.6 Kgs.

9.9 Kgs.

13.2 Kgs.

No. of Falls of Load Chain:

1 Falls

2 Falls

3 Falls

4 Falls

Overall Dimensions:(Head room x Other Dimensions)

950 x 960 x 435 mm

1170 x 960 x 435 mm

1360 x 960 x 535 mm

1360 x 960 x 545 mm

Headroom (Hook Suspension):

950 mm

1170 mm

1460 mm

1460 mm

Headroom (With Monorail Geared Traveling Trolley):

1025 mm

1250 mm

1360 mm

1360 mm

Headroom (With Monorail Electric Traveling Trolley):

1045 mm

1270 mm

1380 mm

1380 mm

Motor:

5.0 HP, 3 Phase, 1440 RPM, Class Fr

5.0 HP, 3 Phase, 1440 RPM, Class F

5.0 HP, 3 Phase, 1440 RPM, Class F

5.0 HP, 3 Phase, 1440 RPM, Class F

Hoisting Speed:

6.8 Mtr./ Min

3.4 Mtr./ Min

2.3 Mtr./ Min

1.7 Mtr./ Min
